FAW 15Ton Single Axle Fuel Tank Truck , ADR/DOT Certified , 18,000L Capacity
![[pics:title]](https://www.hbjlgs.com/static/upload/image/20251011/1760164558876595.jpg)
![[pics:title]](https://www.hbjlgs.com/static/upload/image/20251011/1760164558871739.jpg)
![[pics:title]](https://www.hbjlgs.com/static/upload/image/20251011/1760164549305576.jpg)
![[pics:title]](https://www.hbjlgs.com/static/upload/image/20251011/1760164560651600.jpg)
![[pics:title]](/static/upload/image/20251011/1760164558876595.jpg)
![[pics:title]](/static/upload/image/20251011/1760164558871739.jpg)
![[pics:title]](/static/upload/image/20251011/1760164549305576.jpg)
![[pics:title]](/static/upload/image/20251011/1760164560651600.jpg)
[Vehicle Technical Parameters] | |
Product Name | Fuel Tank Truck |
Curb Weight(Kg) | 5070 |
Boundary Dimension(mm) | 6950*2270*2800 |
Tank Volume(m³) | 20 |
Tank Thickness（mm） | 5 |
Tank Body Material | Carbon Steel |
Compartment | 2-6 As Customer Need |
Operating Ambient Temperature（°C） | -20~45 |
Manhole Cover | European Standard |
Emergency Shut Off Valve | Include |
Oil Gas Recovery Unit | Include |
Anti-Overflow Alarm Device | Include |
Fuel Loading method | Bottom Filling |
Gear Oil Pump Flow(m³/h) | 60 |
Toolbox | As Required |
[Chassis Technical Parameters] | |
Chassis Brand | FAW |
Drive Form | 4*2 LHD RHD Optional |
Steering Device | Power Assisted Steering |
Wheelbase(mm) | 4200 |
Engine Brand | FAW/Xichai 180HP |
Horse Power(Kw) | 132 |
Engine Displacement(ml) | 3800 |
Engine Emission Standard | Euro 3 |
Number of Engine Cylinders | 4 |
Fuel Type | Diesel |
Gearbox | 6-speed transmission |
Front/Rear Axle(t) | 4.5/9 |
Suspension | Multi Leaf Springs |
Brake System | Front/Rear Drum Full Air Braking |
Tires Spec | 8.25R20 16PR |
Cab Configuration | air conditioning, radio, MP3 and USB port,A |
