Small Van Truck 4X2 89HP diesel Euro III Factory Custom Sale
![[pics:title]](https://www.hbjlgs.com/static/upload/other/20251114/1763119531917777.jpeg)
![[pics:title]](https://www.hbjlgs.com/static/upload/other/20251114/1763119531184913.jpeg)
![[pics:title]](https://www.hbjlgs.com/static/upload/other/20251114/1763119531459583.jpeg)
![[pics:title]](https://www.hbjlgs.com/static/upload/other/20251114/1763119530533452.jpeg)
![[pics:title]](/static/upload/other/20251114/1763119531917777.jpeg)
![[pics:title]](/static/upload/other/20251114/1763119531184913.jpeg)
![[pics:title]](/static/upload/other/20251114/1763119531459583.jpeg)
![[pics:title]](/static/upload/other/20251114/1763119530533452.jpeg)
Parameter Category | Detailed Data |
Basic Vehicle Information | |
Announcement Model | BJ5036XXY-D3 |
Vehicle Type | Box Van Truck |
Drive Configuration | 4×2 (2 front steering wheels + 2 rear driving wheels) |
Wheelbase | 3070 mm |
Cargo Box Length Class | 2.8 m |
Engine Model | Wuling Liuji LJ469Q-1AE9 |
Transmission Model | Qingshan MR513B |
Rear Axle Ratio | 5.286 |
Overall Vehicle Length | 4.945 m |
Overall Vehicle Width | 1.735 m |
Overall Vehicle Height | 2.42 m |
Front Track Width | 1338 mm |
Rear Track Width | 1375 mm |
Curb Weight | 1.32 tons (1320 kg) |
Rated Payload Capacity | 1.095 tons (1095 kg) |
Gross Vehicle Weight (GVW) | 2.545 tons (2545 kg) |
Maximum Speed | 115 km/h |
Place of Origin | Suizhou, Hubei (China) |
Tonnage Class | Micro-Card |
Approach Angle | 39° |
Departure Angle | 23° |
Front Overhang/Rear Overhang | 0.605 m / 1.27 m |
License Plate Type | Blue License Plate (Compliant with China’s light-duty vehicle license standards) |
Energy Type | Gasoline |
Engine Parameters | |
Engine Brand | Wuling Liuji |
Engine Model | Wuling Liuji LJ469Q-1AE9 |
Engine Series | Liuji Gasoline 1.3L |
Number of Cylinders | 4 Cylinders |
Fuel Type | Gasoline |
Cylinder Arrangement | In-line |
Displacement | 1.249 L |
Emission Standard | Beijing V Emission (Beijing local fifth-stage emission standard) |
Maximum Output Power | 64 kW |
Maximum Horsepower | 87 HP |
Maximum Torque | 118 N·m |
Maximum Torque Speed | 6000 rpm |
Rated Engine Speed | 4000 rpm |
Transmission Parameters | |
Transmission Model | Qingshan MR513B |
Transmission Brand | Qingshan |
Shifting Mode | Manual |
Number of Forward Gears | 5 Gears |
Number of Reverse Gears | 1 Gear |
Cargo Box Parameters | |
Cargo Box Type | Box-type (Enclosed van structure for cargo protection) |
Cargo Box Length | 2.8 m |
Cargo Box Width | 1.56 m |
Cargo Box Height | 1.57 m |
Internal Cargo Box Width | 1.559999942779 m |
